Technical Specifications
| Rating (KVA) | (1IN 1OUT) | 1KVA | 2KVA | 3KVA | 6KVA | 7.5KVA | 10KVA | |||
|---|---|---|---|---|---|---|---|---|---|---|
| DC Bus | 36VDC | 96VDC | 180VDC | |||||||
| Rating(KVA) | (3IN 1OUT) | 10KVA | 15KVA | 20KVA | 30KVA | 40KVA | ||||
| DC Bus | 240VDC | 360VDC | ||||||||
| Rating(KVA) | (1IN 1OUT) | 6KVA | 10KVA | |||||||
| DC Bus | 180VDC | |||||||||
| Rating | (3IN 3OUT) | 15KVA | 20KVA | 30KVA | 40KVA | 60KVA | 80KVA | 100KVA | 120KVA | 150KVA |
| DC Bus | 360VDC | 384VDC | ||||||||
| Technology | Double Conversion With High Freq-PWM-IGBT | |||||||||
| Input Voltage | 230V1P 415V 3P&N | |||||||||
| Input Window | 230V-+/-15% 415V4/-15% | |||||||||
| Input Frequency | 50Hz4/-5% | |||||||||
| INPUT PFC WITH 100% LOAD | >0.92 for 1P And >0.85 for 3p | |||||||||
| INVERTER | ||||||||||
| Type | IGBT base PWM With Pure Sine Wave | |||||||||
| Nominal Output Voltage | 230V for 1p/415V for 3p | |||||||||
| Reguiation | +/-2% | |||||||||
| Frequency | 50Hz+/-0.5Hz | |||||||||
| Waveform | Pure Sine Wave With Waveform Feedback Correction | |||||||||
| Transient Response | Remains Within +/1% & Recover to Normal Within 20msec | |||||||||
| Overload Capacity | 100% Continuous | |||||||||
| 125% Iminute | ||||||||||
| Efficiency | 95% | |||||||||
| Crest Factor | 3:1 | |||||||||
| inbuilt Galvanic Isolation Transformer | ||||||||||
| GENERAL | ||||||||||
| Bypass Facility | Manual/Static(optional) | |||||||||
| Alarm | Battery low/Overloded/Over Voltage/Under Voltage/Trip | |||||||||
| LCD Display | Charger On/Inverter on/Battery low/Overload/UV/OV | |||||||||
| Encloure Type | IP-20 | |||||||||
| Cooling System | Forced Air | |||||||||
| Acoustic Noise Level | <60db | |||||||||
| Ambient Temp | 0-40 dec CG | |||||||||
| Humidity | Up to 95% RH non Condensing | |||||||||
| Software & Interface | Optional | |||||||||
